Thông số kỹ thuật Mô tả sản phẩm

Sản phẩm	Mainboard - Bo mạch chủ
Tên Hãng	MSI
Model	X299 SLI PLUS
CPU hỗ trợ	Supports Intel^®Core™ X-Series Processor Family for LGA2066 Socket
Chipset	Intel® X299 Chipset
RAM hỗ trợ	Intel^® Core™ X-series Processors (6-core above CPU 78XX/79XX) 8 x DDR4 memory slots, support up to 256GB Quad channel memory architecture with the CPU that supports up to 4-channels DDR4 X-series processor support DDR4 4133+(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/ 3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz Intel^® Core™ X-series Processors (4 core CPU i7-7740X/i5-7640X) 4 x DDR4 memory slots, support up to 64GB Dual channel memory architecture with the CPU that supports up to 2-channels DDR4 X-series processor support DDR4 4500+(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/ 3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz Supports Intel^® Extreme Memory Profile (XMP)
Khe cắm mở rộng	4 x PCIe 3.0 x16 slots Support x16/x16/x8 mode with the 44-lane CPU. Support x16/x8/x4 modes with the 28-lane CPU. Support x8/x8/x0, x8/x4/x4 modes with the 16-lane CPU. 2 x PCIe 3.0 x1 slots
Đa card màn hình	Supports NVIDIA^®SLI™ Technology Supports AMD^®CrossFire™ Technology
Ổ cứng hỗ trợ	Intel^® X299 Chipset 8 x SATA 6Gb/s ports¹ 2 x M.2 slot (Key M)¹ Supports up to PCIe 3.0 x4 and SATA 6Gb/s M2_1 slot supports 2242/ 2260 /2280 storage devices M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices Supports Intel^® Optane™ Memory Ready for all M.2 slots² 1 x U.2 port³ Supports PCIe 3.0 x4 NVMe storage Supports Intel^® Smart Response Technology for Intel Core™ processors⁴ M.2 slots and SATA ports share the same bandwidth. Please refer to page 38 for U.2, M.2 & SATA combination table. Please refer to user manual for Intel^® Optane™ Memory Configuration. PCI_E3 shares bandwidth with U2_1. If you install a PCI_E3 device, the U2_1 will be disabled. The functions will be supported depend on the CPU. Intel^® X299 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0 and RAID1 for M.2 PCIe storage devices¹ M.2 PCIe RAID volume can be created with M.2/Optane Genie. Please refer to user manual for Creating a M.2 PCIe SSD RAID with M.2/Optane Genie.
USB	ASMedia^® ASM3142 Chipset 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel, 1 Type-C port available through the internal USB connector) ASMedia^® ASM1074 Hub 3 x USB 3.1 Gen1 (SuperSpeed USB) ports on the back panel Intel^® X299 Chipset 5 x USB 3.1 Gen1 (SuperSpeed USB) ports (1 Type-A port on the back panel, 4 ports available through the internal USB connectors) 8 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
Âm Thanh	Realtek^® ALC1220 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
LAN / Wireless / Bluetooth	1 x Intel^® I219-V Gigabit LAN controller 1 x Intel^® I211 Gigabit LAN controller
Cổng kết nối ( I/O bên trong)	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 8 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) 1 x USB 3.1 Gen2 Type-C port 1 x 4-pin CPU fan connector 1 x 4-pin Water Pump connector 4 x 4-pin system fan connectors 2 x Front panel connectors 1 x Front panel audio connector 1 x RGB LED connector 1 x TPM module connector 1 x Virtual RAID on CPU connector 1 x Thunderbolt add-on card connector
Cổng kết nối ( I/O Phía sau)	Clear CMOS Button Keyboard / Mouse USB 2.0 Dual Intel^® LAN Golden Audio Connectors Flash BIOS Button USB 2.0 / Flash BIOS USB 3.1 Gen1 USB 3.1 Gen2 Type-A/C Optical S/PDIF-Out
Kích cỡ	12 in. x 9.6 in. (30.5 cm x 24.3 cm) ATX Form Factor

Sản phẩm	Mainboard - Bo mạch chủ
Tên Hãng	MSI
Model	X299 SLI PLUS
CPU hỗ trợ	Supports Intel^®Core™ X-Series Processor Family for LGA2066 Socket
Chipset	Intel® X299 Chipset
RAM hỗ trợ	Intel^® Core™ X-series Processors (6-core above CPU 78XX/79XX) 8 x DDR4 memory slots, support up to 256GB Quad channel memory architecture with the CPU that supports up to 4-channels DDR4 X-series processor support DDR4 4133+(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/ 3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz Intel^® Core™ X-series Processors (4 core CPU i7-7740X/i5-7640X) 4 x DDR4 memory slots, support up to 64GB Dual channel memory architecture with the CPU that supports up to 2-channels DDR4 X-series processor support DDR4 4500+(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/ 3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz Supports Intel^® Extreme Memory Profile (XMP)
Khe cắm mở rộng	4 x PCIe 3.0 x16 slots Support x16/x16/x8 mode with the 44-lane CPU. Support x16/x8/x4 modes with the 28-lane CPU. Support x8/x8/x0, x8/x4/x4 modes with the 16-lane CPU. 2 x PCIe 3.0 x1 slots
Đa card màn hình	Supports NVIDIA^®SLI™ Technology Supports AMD^®CrossFire™ Technology
Ổ cứng hỗ trợ	Intel^® X299 Chipset 8 x SATA 6Gb/s ports¹ 2 x M.2 slot (Key M)¹ Supports up to PCIe 3.0 x4 and SATA 6Gb/s M2_1 slot supports 2242/ 2260 /2280 storage devices M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices Supports Intel^® Optane™ Memory Ready for all M.2 slots² 1 x U.2 port³ Supports PCIe 3.0 x4 NVMe storage Supports Intel^® Smart Response Technology for Intel Core™ processors⁴ M.2 slots and SATA ports share the same bandwidth. Please refer to page 38 for U.2, M.2 & SATA combination table. Please refer to user manual for Intel^® Optane™ Memory Configuration. PCI_E3 shares bandwidth with U2_1. If you install a PCI_E3 device, the U2_1 will be disabled. The functions will be supported depend on the CPU. Intel^® X299 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0 and RAID1 for M.2 PCIe storage devices¹ M.2 PCIe RAID volume can be created with M.2/Optane Genie. Please refer to user manual for Creating a M.2 PCIe SSD RAID with M.2/Optane Genie.
USB	ASMedia^® ASM3142 Chipset 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel, 1 Type-C port available through the internal USB connector) ASMedia^® ASM1074 Hub 3 x USB 3.1 Gen1 (SuperSpeed USB) ports on the back panel Intel^® X299 Chipset 5 x USB 3.1 Gen1 (SuperSpeed USB) ports (1 Type-A port on the back panel, 4 ports available through the internal USB connectors) 8 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
Âm Thanh	Realtek^® ALC1220 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
LAN / Wireless / Bluetooth	1 x Intel^® I219-V Gigabit LAN controller 1 x Intel^® I211 Gigabit LAN controller
Cổng kết nối ( I/O bên trong)	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 8 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) 1 x USB 3.1 Gen2 Type-C port 1 x 4-pin CPU fan connector 1 x 4-pin Water Pump connector 4 x 4-pin system fan connectors 2 x Front panel connectors 1 x Front panel audio connector 1 x RGB LED connector 1 x TPM module connector 1 x Virtual RAID on CPU connector 1 x Thunderbolt add-on card connector
Cổng kết nối ( I/O Phía sau)	Clear CMOS Button Keyboard / Mouse USB 2.0 Dual Intel^® LAN Golden Audio Connectors Flash BIOS Button USB 2.0 / Flash BIOS USB 3.1 Gen1 USB 3.1 Gen2 Type-A/C Optical S/PDIF-Out
Kích cỡ	12 in. x 9.6 in. (30.5 cm x 24.3 cm) ATX Form Factor

Xem đầy đủ thông số kỹ thuật

Giới thiệu Mainboard MSI X299 SLI PLUS

Mainboard MSI X299 SLI PLUS hỗ trợ những chuẩn lưu trữ mới nhất trên thị trường. Việc này giúp cho bạn có thể kết nối với những thiết bị lưu trữ nhanh nhất, rất hữu dụng cho bạn khi làm việc với những tác vụ nặng. Khởi động ứng dụng nhanh hơn, truyền tải dữ liệu nhanh hơn tăng khả nặng tạo dựng các nội dung số...

X299 SLI PLUS

Xem tất cả

Bình luận và đánh giá

0/5

0 đánh giá và nhận xét

0 đánh giá

Bạn đánh giá sao sản phẩm này

Đánh giá ngay

Xem thêm đánh giá

Hỏi và đáp

Gửi Gửi

Đính kèm ảnh

Mainboard MSI X299 SLI PLUS

Name: Mainboard MSI X299 SLI PLUS
Brand: MSI
SKU: SP000172
Availability: InStock
Rating: 4.9 (5 reviews)

Mã SP: SP000172

0.0 (0 đánh giá)

5684

Bảo hành: 36 Tháng

5.790.000đ

~~6.800.000 đ~~

Tiết kiệm: 1.010.000đ

Hoặc

Trả góp

496.686/tháng

Xem chi nhánh đang còn hàng

Showroom Miền Bắc:

Showroom Miền Nam:

Lưu ý: Sản phẩm có thể điều chuyển kho theo yêu cầu của quý khách.

TRẢ GÓP MUA NGAY

Thêm vào giỏ
