Mainboard ASUS WS C621E SAGE

Name: Mainboard ASUS WS C621E SAGE
Brand: ASUS
SKU: SP001676
Availability: InStock
Rating: 10 (7 reviews)

Mã SP: SP001676

Đánh giá: 7

Bình luận: 0

Bảo hành: 36 Tháng

Tình trạng: Còn hàng

Xem chi nhánh đang có còn hàng

Showroom Miền Bắc:

Showroom Miền Nam:

Chú ý: Sản phẩm có thể điều chuyển kho theo yêu cầu của quý khách.

18.990.000đ

18.990.000₫

Tiết kiệm đ

Số lượng:

−

Thêm vào giỏ hàng

ĐẶT MUA NGAY Giao hàng tận nơi nhanh chóng TRẢ GÓP QUA HỒ SƠ Chỉ từ 2.665.000₫/ tháng TRẢ GÓP QUA THẺ Chỉ từ 1.332.500₫/ tháng

Yên tâm mua hàng

Cam kết giá tốt nhất thị trường.

Sản phẩm mới 100%.

Lỗi 1 đổi 1 ngay lập tức.

Hỗ trợ trả góp - Thủ tục nhanh gọn.

Sản phẩm tương tự

Giới thiệu Mainboard ASUS WS C621E SAGE

Mainboard ASUS WS C621E SAGE hỗ trợ lên đến 4-Way NVIDIA^® SLI^® and AMD^® Crossfire X™ và 12 khe ram bus 2933 với tổng dung lương bộ nhớ hỗ trợ cực lớn Max 1536GB. Hỗ trợ RAM ECC tự sửa lỗi đem lại sự an tâm tuyệt đối cho bạn...

WS C621E SAGE Review

Tham khảo cấu hình 1.8 tỷ được build bởi Mainboard ASUS WS C621E SAGE: TẠI ĐÂY

Xem tất cả

Bình luận và đánh giá

0/5

0 đánh giá và nhận xét

0 đánh giá

Bạn đánh giá sao sản phẩm này

Đánh giá ngay

Hỏi và đáp

Gửi Gửi

Đính kèm ảnh

Thông số kỹ thuật

Sản phẩm	Main - Bo mạch chủ
Tên Hãng	ASUS
Model	WS C621E SAGE
CPU hỗ trợ	Dual Intel® Socket P (LGA 3647) for Intel® 1st and 2nd Xeon® Scalable Processors Family (205W)
Chipset	Build in Intel® C621
RAM hỗ trợ	12 x DIMM, Max. 1536GB, DDR4 2933/2666/2400 MHz RDIMM, LR-DIMM Memory * Please refer to ASUS AVL for the latest update. * Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Hình ảnh	Integrated Graphics Processor VGA port(Optional) - Supports VGA with max. resolution 1920 x 1200 @ 60 Hz Aspeed AST2500 with 64 MB VRAM
Hỗ trợ đa card màn hình	Supports NVIDIA® 4-Way SLI™ Technology ¹ Supports AMD 4-Way CrossFireX Technology ¹
Khe cắm mở rộng	3 x PCIe 3.0 x16 (x16 mode) 2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8) 2 x PCIe 3.0 x16 (x8 mode)
Lưu trữ	Intel® C621 Chipset : 8 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10 ASMedia® SATA 6Gb/s controller : 2 x SATA 6Gb/s port(s), 4 x U.2 connector, 1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)
LAN / Wireless / Bluetooth	Intel® I210-AT, 2 x Gigabit LAN Controller(s)
Âm Thanh	Realtek® S1220A 7.1-Channel High Definition Audio CODEC ² - Power pre-regulator reduces power input noise to ensure consistent performance - Impedance sense for front and rear headphone outputs - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality SNR stereo playback output and 113 dB SNR recording input (Line-in) - Front panel audio connector (AAFP) - Supports up to 32-Bit/192kHz playback Audio Feature :* - DTS Connect - DTS Headphone:X - Optical S/PDIF out port(s) at back panel - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
USB	ASMedia® USB 3.1 Gen 2 controller : 2 x USB port(s) (2 at back panel, , Type-A + USB Type-C^TM) Intel® C621 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board) Intel® C621 Chipset : 4 x USB 2.0 port(s) (2 at back panel, , 2 at mid-board)
Workstation Feature	ProCool Power Connector USB BIOS Flashback^® ASUS PIKE SAS upgrade kit*³
Tính năng đặc biệt	Gamer's Guardian: - DIGI+ VRM - SafeSlot ASUS Digital Power Design : - Industry leading Digital 7 + 1 Phase CPU Power Design - Industry leading Digital 2 Phase DRAM Power Design ASUS Exclusive Features : - Front Panel USB 3.0 Support ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-DIMM M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M.2 and U.2)
Cổng kết nối ( I/O bên trong)	2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 1 x TPM header 1 x COM port(s) connector(s) 10 x SATA 6Gb/s connector(s) 1 x VROC_HW_Key 2 x CPU Fan connector(s) (2 x 4 -pin) 7 x Chassis Fan connector(s) *⁵ 2 x 8-pin EATX 12 V Power connector 1 x 24-pin EATX Power connector(s) 1 x VGA connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x AUX panel header(s) 1 x SMBus header(s) 1 x 6-pin EATX 12V_3 Power connector 1 x System panel connector 4 x U.2 Connector (support U.2 NVMe device)
Cổng kết nối ( I/O Phía sau)	1 x PS/2 keyboard/mouse combo port(s) 2 x LAN (RJ45) port(s) 2 x USB 3.1 Gen 2 *⁴ 4 x USB 3.1 Gen 1 4 x USB 2.0 1 x Optical S/PDIF out 1 x USB BIOS Flashback^® Button(s) 1 x 8-channel Audio I/O
Kích cỡ	EEB Form Factor 12 inch x 13 inch ( 30.5 cm x 33 cm )
Environment	Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing)
Ghi chú	* Dual Intel® Socket P/LGA 3647 (Square) 1 Actual number of multi-graphic support differes per Vendors' graphic cards. Please check with vendor beforehand. 2 Due to limitation in HDA bandwidth, 32-Bit/192kHz is not supported for 8-channel audio. 32-Bit/192kHz is only available under Windows 10 3 Please check AVL list for supported add on card 4 1 x Type A, 1 x Type C *5 5 x Front, 2 x Rear

Sản phẩm	Main - Bo mạch chủ
Tên Hãng	ASUS
Model	WS C621E SAGE
CPU hỗ trợ	Dual Intel® Socket P (LGA 3647) for Intel® 1st and 2nd Xeon® Scalable Processors Family (205W)
Chipset	Build in Intel® C621
RAM hỗ trợ	12 x DIMM, Max. 1536GB, DDR4 2933/2666/2400 MHz RDIMM, LR-DIMM Memory * Please refer to ASUS AVL for the latest update. * Actual memory frequency differs from Intel CPU types and memory module. Please check Intel official site for more detail about the memory types supported by each CPU.
Hình ảnh	Integrated Graphics Processor VGA port(Optional) - Supports VGA with max. resolution 1920 x 1200 @ 60 Hz Aspeed AST2500 with 64 MB VRAM
Hỗ trợ đa card màn hình	Supports NVIDIA® 4-Way SLI™ Technology ¹ Supports AMD 4-Way CrossFireX Technology ¹
Khe cắm mở rộng	3 x PCIe 3.0 x16 (x16 mode) 2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8) 2 x PCIe 3.0 x16 (x8 mode)
Lưu trữ	Intel® C621 Chipset : 8 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10 ASMedia® SATA 6Gb/s controller : 2 x SATA 6Gb/s port(s), 4 x U.2 connector, 1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)
LAN / Wireless / Bluetooth	Intel® I210-AT, 2 x Gigabit LAN Controller(s)
Âm Thanh	Realtek® S1220A 7.1-Channel High Definition Audio CODEC ² - Power pre-regulator reduces power input noise to ensure consistent performance - Impedance sense for front and rear headphone outputs - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality SNR stereo playback output and 113 dB SNR recording input (Line-in) - Front panel audio connector (AAFP) - Supports up to 32-Bit/192kHz playback Audio Feature :* - DTS Connect - DTS Headphone:X - Optical S/PDIF out port(s) at back panel - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity - Unique de-pop circuit: Reduces start-up popping noise to audio outputs
USB	ASMedia® USB 3.1 Gen 2 controller : 2 x USB port(s) (2 at back panel, , Type-A + USB Type-C^TM) Intel® C621 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board) Intel® C621 Chipset : 4 x USB 2.0 port(s) (2 at back panel, , 2 at mid-board)
Workstation Feature	ProCool Power Connector USB BIOS Flashback^® ASUS PIKE SAS upgrade kit*³
Tính năng đặc biệt	Gamer's Guardian: - DIGI+ VRM - SafeSlot ASUS Digital Power Design : - Industry leading Digital 7 + 1 Phase CPU Power Design - Industry leading Digital 2 Phase DRAM Power Design ASUS Exclusive Features : - Front Panel USB 3.0 Support ASUS Q-Design : - ASUS Q-Shield - ASUS Q-Code - ASUS Q-DIMM M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M.2 and U.2)
Cổng kết nối ( I/O bên trong)	2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 1 x TPM header 1 x COM port(s) connector(s) 10 x SATA 6Gb/s connector(s) 1 x VROC_HW_Key 2 x CPU Fan connector(s) (2 x 4 -pin) 7 x Chassis Fan connector(s) *⁵ 2 x 8-pin EATX 12 V Power connector 1 x 24-pin EATX Power connector(s) 1 x VGA connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x AUX panel header(s) 1 x SMBus header(s) 1 x 6-pin EATX 12V_3 Power connector 1 x System panel connector 4 x U.2 Connector (support U.2 NVMe device)
Cổng kết nối ( I/O Phía sau)	1 x PS/2 keyboard/mouse combo port(s) 2 x LAN (RJ45) port(s) 2 x USB 3.1 Gen 2 *⁴ 4 x USB 3.1 Gen 1 4 x USB 2.0 1 x Optical S/PDIF out 1 x USB BIOS Flashback^® Button(s) 1 x 8-channel Audio I/O
Kích cỡ	EEB Form Factor 12 inch x 13 inch ( 30.5 cm x 33 cm )
Environment	Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing)
Ghi chú	* Dual Intel® Socket P/LGA 3647 (Square) 1 Actual number of multi-graphic support differes per Vendors' graphic cards. Please check with vendor beforehand. 2 Due to limitation in HDA bandwidth, 32-Bit/192kHz is not supported for 8-channel audio. 32-Bit/192kHz is only available under Windows 10 3 Please check AVL list for supported add on card 4 1 x Type A, 1 x Type C *5 5 x Front, 2 x Rear

Xem đầy đủ thông số kỹ thuật
