Mainboard MSI MEG Z590I UNIFY

CPU hỗ trợ

Supports 10th Gen Intel^® Core™ Processors, 11th Gen Intel^® Core™ Processors, Pentium^® Gold and Celeron^® processors

Processor socket LGA1200

Chipset

RAM hỗ trợ

• 2x DDR4 memory slots, support up to 64GB
• Supports 1R 2133/2666/2933 MHz for 10th Gen Intel^®CPU (by JEDEC & POR)
• Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel^®CPU (by JEDEC & POR)
• Max overclocking frequency:
  • 1DPC 1R Max speed up to 5600 MHz
  • 1DPC 2R Max speed up to 4800+ MHz
• Supports Dual-Channel mode
• Supports non-ECC, un-buffered memory
• Supports Intel^® Extreme Memory Profile [XMP]

• 1x PCIe x16 slot
  • Support up to PCIe 4.0 for 11th Gen Intel^® CPU
  • Support up to PCIe 3.0 for 11th Gen Intel^® CPU

Hình ảnh

1x HDMI 2.0b with HDR port, supports a maximum resolution of 4K 60Hz

1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz

Chỉ khả dụng trên các bộ xử lý có đồ họa tích hợp.
Thông số kỹ thuật đồ họa có thể khác nhau tùy thuộc vào CPU được cài đặt.

• Intel^® JHL8540Thunderbolt™ 4 Controller
• 2x Thunderbolt™ 4 (USB-C) ports on the back panel
  • Support up to 40Gbps transfer rate with Thunderbolt devices
  • Support up to 20Gbps transfer rate with USB4 devices
  • Support up to 10Gbps transfer rate with USB 3.2 devices
  • Support up to 5V/3A ,15W power charging
  • Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices
  • Supports up to 8K display (need to connect the DisplayPort of the motherboard or discrete graphics card to the Mini DisplayPort Input port on the back panel)

Lưu trữ

• 4x SATA 6Gb/s ports (from Z590 chipset)
• 2x M.2 slots (Key M)
  • M2_1 slot
    • Supports up to PCIe 4.0 x4 for 11th Gen Intel^® CPU (From CPU)
    • Supports up to PCIe 3.0 x4 & SATA 6Gb/s for 10th Gen Intel^® CPU (From Z590 chipset)
    • Supports 2280 storage devices
  • M2_2 slot (from Z590 chipset)
    • Supports PCIe 3.0 x4 only
    • Supports 2280 storage devices
    • Intel^® Optane™ Memory Ready*
• Supports Intel^® Smart Response Technology for Intel Core™ processors

* Trước khi sử dụng mô-đun bộ nhớ Intel® Optane ™, hãy đảm bảo rằng bạn đã cập nhật trình điều khiển và BIOS lên phiên bản mới nhất từ trang web MSI.

Intel^® Z590 Chipset

Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices

Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

USB

Intel® Z590 Chipset

3x USB 3.2 Gen 2 10Gbps ports (2 Type-A port on the back panel, 1 Type-C internal connector)

4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)

4x USB 2.0 ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connectors)

Âm Thanh

Realtek^® ALC4080

7.1-Channel High Definition Audio

LAN

1x Inte^® I225-V 2.5Gbps LAN controller

Intel^®Wi-Fi 6E AX210

The Wireless module is pre-installed in the M.2 [Key-E] slot

Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz ^[1](160MHz) up to 2.4Gbps

Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth^® 5.2^[2], FIPS, FISMA

1. Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in WIN10 21H1.

2. Bluetooth 5.2 will be ready in WIN10 21H1.

Cổng kết nối (I/O bên trong)

1x 24-pin ATX main power connector

1x 8-pin ATX 12V power connector

4x SATA 6Gb/s connectors

2x M.2 slots [M-Key]

1x USB 3.2 Gen2 10Gbps Type-C port

1x USB 3.2 Gen1 5Gbps connector [supports additional 2 USB 3.2 Gen1 5Gbps ports]

1x USB 2.0 connector [supports additional 2 USB 2.0 ports]

1x 4-pin CPU fan connector

1x 4-pin water-pump fan connector

1x 4-pin system fan connector

1x Front panel audio connector

2x System panel connectors

1x Chassis Intrusion connector

1xTPM module connector

4x EZ Debug LED

1x 3-pin RAINBOW LED connectors

Cổng kết nối ( I/O Phía sau)

1. DisplayPort
2. USB 2.0
3. 2.5G LAN
4. Wi-Fi /Bluetooth
5. Thunderbolt 4 40Gbps (Type-C)
6. HD Audio Connectors
7. Clear CMOS Button
8. HDMI
9. USB 3.2 Gen1 5Gbps (Type-A)
10. USB 3.2 Gen2 10Gbps (Type-A)
11. Mini DisplayPort Input (for Thunderbolt passthrough)

Kích cỡ

6.7 in. x 6.7 in. [17.0 cm x 17.0 cm]

Mini-ITX Form Factor
